Build a Reusable PCF Dialog Framework for Dynamics 365

If you open Custom Page modals from many places in your Dynamics 365 app, you quickly notice a problem: the same JavaScript gets copied again and again, each button hard-codes its own page name and sizes, and one small change means editing a dozen web resources. The fix is a reusable PCF dialog framework — a single, well-designed layer that opens any Custom Page as a modal with consistent behavior.

This article — part of our series on hosting PCF controls in modal popups — shows you how to build that framework step by step, in plain language.

Why You Need a Framework

Without a shared layer, every dialog is a one-off. That leads to duplicated code, inconsistent dialog sizes, and no single place to add logging, error handling, or a loading state. A framework solves all of this by giving you one function to open any dialog and one place to change behavior.

• Consistency — every dialog looks and behaves the same.
• Less code — buttons just say “open this page with this record.”
• Easy maintenance — change sizing or error handling in one file.
• Reusability — new dialogs need almost no new code.

The Core Idea

The framework is a single helper (a JavaScript web resource) that wraps Xrm.Navigation.navigateTo(). Every ribbon button calls the helper with a small options object instead of writing its own navigation code.

// cloudverve_dialogFramework.js  — one shared web resource
var CloudVerve = window.CloudVerve || {};
CloudVerve.Dialog = (function () {

    function open(config, primaryControl) {
        var ctx = primaryControl;
        var recordId = config.recordId ||
            (ctx && ctx.data.entity.getId().replace(/[{}]/g, ""));
        var entityName = config.entityName ||
            (ctx && ctx.data.entity.getEntityName());

        var pageInput = {
            pageType: "custom",
            name: config.pageName,          // logical name of the Custom Page
            recordId: recordId,
            entityName: entityName
        };

        var options = {
            target: 2,                      // modal dialog
            position: config.position || 1, // center by default
            width:  config.width  || { value: 60, unit: "%" },
            height: config.height || { value: 70, unit: "%" },
            title:  config.title  || "Dialog"
        };

        return Xrm.Navigation.navigateTo(pageInput, options).then(
            function () { if (config.onClose) config.onClose(ctx); },
            function (e) { CloudVerve.Dialog._error(e); }
        );
    }

    return {
        open: open,
        _error: function (e) { console.error("[CloudVerve.Dialog]", e); }
    };
})();

Calling the Framework from a Button

Now any ribbon button is a one-liner. It describes what to open, not how:

function openCustomer360(primaryControl) {
    CloudVerve.Dialog.open({
        pageName: "cr123_customer360_page",
        title: "Customer 360",
        width:  { value: 70, unit: "%" },
        height: { value: 80, unit: "%" },
        onClose: function (ctx) { ctx.data.refresh(false); }
    }, primaryControl);
}

Every dialog in your app now flows through the same code path — so sizing, titles, error handling, and the post-close refresh are all consistent.

Adding Shared Features

Because everything runs through one function, you can add powerful features in a single place and every dialog gets them for free:

• Standard sizes — small, medium, large presets instead of magic numbers.
• Loading indicators — show a spinner while the page loads.
• Central error handling — one place to log and show friendly messages.
• Telemetry — track which dialogs are used and how often.
• Auto-refresh — refresh the parent form or a named subgrid on close.

Best Practices

• Keep the framework in one web resource and version it carefully.
• Use named size presets so dialogs stay visually consistent.
• Always pass only the data the page needs.
• Handle the no-record case (dialogs opened from a grid or the nav bar).
• Document the config options so any developer can add a dialog.

Conclusion

A reusable PCF dialog framework turns dozens of copy-pasted scripts into a single, reliable helper. You write less code, ship consistent dialogs, and gain one place to improve every popup at once. It’s the foundation that makes the rest of this series — passing data, AI panels, multi-dialog flows, and wizards — simple to build.
