Refresh Model-Driven Forms After Closing Custom Pages

You open a Custom Page modal, the user edits data, the dialog closes — and the form behind it still shows the old values. Frustrating, and a common complaint. The fix is knowing exactly how to refresh a model-driven form after closing a Custom Page so the UI always reflects what just changed.

This guide — part of our series on hosting PCF controls in modal popups — covers every refresh you might need, in plain language.

Why the Form Doesn’t Refresh Automatically

A Custom Page runs in its own context. When it writes to Dataverse and closes, the model-driven form has no idea anything changed — it’s still showing data it loaded earlier. You have to tell it to reload.

The Key: the navigateTo Success Callback

Xrm.Navigation.navigateTo() returns a promise that resolves when the dialog closes. That callback is where you refresh:

function openAndRefresh(primaryControl) {
    const formContext = primaryControl;
    Xrm.Navigation.navigateTo(
        { pageType: "custom", name: "cr123_editor_page",
          recordId: formContext.data.entity.getId().replace(/[{}]/g, ""),
          entityName: formContext.data.entity.getEntityName() },
        { target: 2, width: { value: 60, unit: "%" } }
    ).then(function () {
        // runs after the dialog closes
        formContext.data.refresh(false);          // reload the form
    });
}

Refreshing Specific Parts

Sometimes reloading the whole form is overkill. You can refresh just what changed:

• Whole form: formContext.data.refresh(false) (false = don’t prompt to save).
• A subgrid: formContext.getControl("SubgridName").refresh().
• A timeline: refresh it like a subgrid using its control name.
• Ribbon/command bar: formContext.ui.refreshRibbon() to re-evaluate button rules.
• A single field’s data: reload the attribute or refresh the form section.

Only Refresh When Something Changed

If the user cancels, there’s no need to reload. Have the Custom Page return a result (see Pass Data Between Custom Pages and PCF Controls), and refresh only when the result says data was saved:

.then(function (result) {
    if (result && result.saved) {
        formContext.data.refresh(false);
    }
});

Common Pitfalls

• Refreshing too early: do it in the .then(), after the dialog closes.
• Wrong control name: subgrid/timeline names are case-sensitive and must match the form.
• Unwanted save prompt: pass false to refresh to skip the save dialog.
• Stale ribbon: call refreshRibbon() if button visibility depends on the change.

Conclusion

Refreshing a model-driven form after a Custom Page closes is all about the navigateTo success callback — and choosing the right scope: whole form, subgrid, timeline, or ribbon. Refresh only when data actually changed, and your users always see current data without a manual reload.
